| Size | Inside (mm) | Outside (mm) | Working Pressure | Burst Pressure | Bend Radius | Weight | Length | |||||||
| DN | inch | mm | Dash | Min | Max | Min | Max | Bar | Psi | Bar | Psi | mm | kg/m | M |
| 6 | 1/4″ | 6.4 | -4 | 5.9 | 6.9 | 12.6 | 14.2 | 75 | 1100 | 300 | 4300 | 40 | 0.11 | 50/100 |
| 8 | 5/16″ | 7.9 | -5 | 7.4 | 8.4 | 14.1 | 15.7 | 68 | 986 | 272 | 3945 | 50 | 0.15 | 50/100 |
| 10 | 3/8″ | 9.5 | -6 | 9.0 | 10.0 | 15.7 | 17.3 | 63 | 920 | 252 | 3680 | 60 | 0.16 | 50/100 |
| 13 | 1/2″ | 12.7 | -8 | 12.1 | 13.3 | 18.7 | 20.7 | 58 | 840 | 232 | 3360 | 70 | 0.21 | 50/100 |
| 16 | 5/8″ | 15.9 | -10 | 15.3 | 16.5 | 22.9 | 24.9 | 50 | 730 | 200 | 2900 | 90 | 0.28 | 50/100 |
| 19 | 3/4” | 19.0 | -12 | 18.2 | 19.8 | 26.0 | 28.0 | 45 | 650 | 180 | 2610 | 110 | 0.35 | 50 |
| 25 | 1″ | 25.4 | -16 | 24.6 | 26.2 | 32.9 | 35.9 | 40 | 600 | 160 | 2320 | 150 | 0.50 | 50 |
●Black
