| Size | Inside (mm) | Outside (mm) | Working Pressure | Burst Pressure | Bend Radius | Weight | Length | |||||||
| DN | inch | mm | Dash | Min | Max | Min | Max | Bar | Psi | Bar | Psi | mm | kg/m | M |
| 5 | 3/16″ | 4.8 | -3 | 4.4 | 5.2 | 10.3 | 11.9 | 35 | 508 | 140 | 2030 | 50 | 0.10 | 50/100 |
| 6 | 1/4″ | 6.4 | -4 | 5.9 | 6.9 | 11.9 | 13.5 | 28 | 400 | 112 | 1620 | 64 | 0.11 | 50/100 |
| 8 | 5/16″ | 7.9 | -5 | 7.4 | 8.4 | 13.5 | 15.1 | 28 | 400 | 112 | 1620 | 76 | 0.13 | 50/100 |
| 10 | 3/8″ | 9.5 | -6 | 9.0 | 10.0 | 15.1 | 16.7 | 28 | 400 | 112 | 1620 | 76 | 0.16 | 50/100 |
| 13 | 1/2″ | 12.7 | -8 | 12.1 | 13.3 | 17.7 | 19.7 | 28 | 400 | 112 | 1620 | 102 | 0.22 | 50/100 |
| 16 | 5/8″ | 15.9 | -10 | 15.3 | 16.5 | 22.2 | 23.8 | 24 | 350 | 96 | 1400 | 107 | 0.27 | 50/100 |
| 19 | 3/4” | 19.0 | -12 | 18.2 | 19.8 | 25.4 | 27.8 | 21 | 300 | 84 | 1200 | 152 | 0.37 | 50 |
| 25 | 1″ | 25.4 | -16 | 24.6 | 26.2 | 32.2 | 34.6 | 17 | 250 | 70 | 1000 | 203 | 0.48 | 50 |
●Black
